Bug #65378
Scaling/cropping images in GIFBUILDER does not work
| Status: | Resolved | Start date: | 2015-02-27 | |
|---|---|---|---|---|
| Priority: | Should have | Due date: | ||
| Assigned To: | - | % Done: | 100% |
|
| Category: | Image Generation | Spent time: | - | |
| Target version: | next-patchlevel | |||
| TYPO3 Version: | 6.2 | Is Regression: | Yes | |
| PHP Version: | Sprint Focus: | |||
| Complexity: | medium |
Description
I am using following TypoScript to center an image on a specified rectangle.
This will not work after updating to 6.2.10
lib.prodImage = COA
lib.prodImage {
10 = IMAGE
10 {
file = GIFBUILDER
file {
format = jpg
workArea = 0,0,200,200
XY = 200,200
backColor = #ffffff
quality = 95
10 = IMAGE
10 {
file.import.current = 1
file.maxH = 200
file.maxW = 200
align = c,c
}
}
}
}
Related issues
Associated revisions
[BUGFIX] Regression when scaling/cropping in GIFBUILDER
The fix for issue #64224 introduced a regression in GIFBUILDER
resulting in problems with image scaling/cropping.
For $fileInfo and $maskInfo: use 'processedFile' for FAL files
if available and correctly distinguish between FAL- and non-FAL files
otherwise by checking for 'origFile'.
Resolves: #65378
Related: #64224
Releases: master, 6.2
Change-Id: Ib472bdcdc7f814e50ebd18e084f5fbe7d09fc410
Reviewed-on: http://review.typo3.org/37483
Reviewed-by: Stephan Großberndt <stephan@grossberndt.de>
Tested-by: Stephan Großberndt <stephan@grossberndt.de>
Reviewed-by: Frans Saris <franssaris@gmail.com>
Tested-by: Stefan Froemken <froemken@gmail.com>
Tested-by: Christoph Lehmann <christoph.lehmann@networkteam.com>
Tested-by: Philipp Mueller <philipp.mueller@lavitto.ch>
Reviewed-by: Christian Kuhn <lolli@schwarzbu.ch>
Tested-by: Christian Kuhn <lolli@schwarzbu.ch>
[BUGFIX] Regression when scaling/cropping in GIFBUILDER
The fix for issue #64224 introduced a regression in GIFBUILDER
resulting in problems with image scaling/cropping.
For $fileInfo and $maskInfo: use 'processedFile' for FAL files
if available and correctly distinguish between FAL- and non-FAL files
otherwise by checking for 'origFile'.
Resolves: #65378
Related: #64224
Releases: master, 6.2
Change-Id: Ib472bdcdc7f814e50ebd18e084f5fbe7d09fc410
Reviewed-on: http://review.typo3.org/37533
Reviewed-by: Christian Kuhn <lolli@schwarzbu.ch>
Tested-by: Christian Kuhn <lolli@schwarzbu.ch>
[BUGFIX] Temporary filename collision in imageMagickConvert()
Add more entropy to the temporary filename used by imageMagickConvert()
to ensure different processing configurations resulting in the same
output dimensions get different temporary names.
In combination with LocalDriver moving the temporary file to a different
location and file_exists_typo3temp_file() having a 30s window where it
doesn't detect the moved file (when the user enabled
$TYPO3_CONF_VARS['GFX']['enable_typo3temp_db_tracking']) this
leads to entries in the sys_processed_file table with a width and
height of 0, thus referencing the original file and resulting in
unscaled images showing in the frontend.
Resolves: #65842
Resolves: #63519
Resolves: #60215
Related: #65378
Releases: 6.2
Change-Id: I42748d0899bf1e24f9f92f2e55802d64309c5704
Reviewed-on: http://review.typo3.org/39373
Reviewed-by: Stephan Großberndt <stephan@grossberndt.de>
Reviewed-by: Frans Saris <franssaris@gmail.com>
Reviewed-by: Andreas Fernandez <typo3@scripting-base.de>
Tested-by: Andreas Fernandez <typo3@scripting-base.de>
Reviewed-by: Markus Klein <markus.klein@typo3.org>
Tested-by: Markus Klein <markus.klein@typo3.org>
History
#1 Updated by Geddo no-lastname-given 5 months ago
same here. I'm using gifbuilder to scale images + watermarks etc. Everything was fine in 6.2.9 and is now messed up in 6.2.10
Here is a test-snippet
page = PAGE
page {
config {
no_cache = 1
}
10 = IMAGE
10 {
file = GIFBUILDER
file {
format = jpg
quality = 90
XY = 500,500
10 = IMAGE
10 {
file = fileadmin/template/img/test.jpg
file.width = 500c # HAS NO EFFECT in 6.2.10!
file.height= 500c # HAS NO EFFECT in 6.2.10!
}
}
}
}
OK folks so here is the deal: https://review.typo3.org/#/c/36180/3/typo3/sysext/frontend/Classes/Imaging/GifBuilder.php
$fileInfo3 gets the correctly scaled, processed image while $fileInfo['originalFile']->getForLocalProcessing(FALSE) delivers the original, unscaled image.
So I don't know why this condition was implemented but at least it should rescale the originalFile like the one in $fileInfo3
#2 Updated by Claus Harup 5 months ago
I have the same problem with any GIFBUILDER configuration after upgrading to 6.2.10 :-|
#4 Updated by Philipp Mueller 5 months ago
Since TYPO3 6.2.10 I've the same problem like Geddo with GIFBUILDER. The problem occurs with width= and height=, too.
I work with:- GraphicsMagick 1.3.18 2013-03-10 Q8
- PHP 5.5.9
- Ubuntu 14.04.2 LTS.
#5 Updated by Gerrit Code Review 5 months ago
- Status changed from New to Under Review
Patch set 1 for branch master of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37483
#6 Updated by Adrian no-lastname-given 5 months ago
Same here. After upgrading TYPO3 from version 6.2.9 to 6.2.10 the scaling images using GIFBUILDER didn't work. When I'm testing image processing in Instal Tool everything looks ok, byt when I want to change img using GIFBUILDER scaling img didn't work. I'm using GIFBUILDER to adding watermark to yag gallery.
#7 Updated by Gerrit Code Review 5 months ago
Patch set 2 for branch master of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37483
#8 Updated by Gerrit Code Review 5 months ago
Patch set 3 for branch master of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37483
#9 Updated by Gerrit Code Review 5 months ago
Patch set 4 for branch master of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37483
#10 Updated by Stephan Großberndt 5 months ago
- Subject changed from Typo3 6.2.10 Gifbuilder to Scaling/cropping images in GIFBUILDER does not work
- Target version set to next-patchlevel
- Complexity set to medium
- Is Regression changed from No to Yes
This is a regression in TYPO3 CMS 6.2.10 caused by https://review.typo3.org/#/c/36180
#11 Updated by Gerrit Code Review 5 months ago
Patch set 5 for branch master of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37483
#12 Updated by Stephan grass 5 months ago
Under php 5.4.34 GifBuilder.php will cause the error:
Parse error: syntax error, unexpected 'class' (T_CLASS), expecting identifier (T_STRING) or variable (T_VARIABLE) or '{' or '$' in /Users/stephangrass/Documents/_Webs_/MR-Chemie/typo3/typo3_src-6.2.10/typo3/sysext/frontend/Classes/Imaging/GifBuilder.php on line 141
#13 Updated by Christian Kuhn 5 months ago
@Stephan: I can not confirm your "fatal" report (our test environment would also have found that in travis-ci for php 5.4 on 6.2.10)
#14 Updated by Gerrit Code Review 5 months ago
Patch set 1 for branch TYPO3_6-2 of project Packages/TYPO3.CMS has been pushed to the review server.
It is available at http://review.typo3.org/37533
#15 Updated by Torben Hansen 5 months ago
- Status changed from Under Review to Resolved
- % Done changed from 0 to 100
Applied in changeset ef5f6cc8ee556c66caf8787635ef049a68e88006.
#16 Updated by Ralph Brugger 5 months ago
Under php 5.4.34 GifBuilder.php will cause the error:
Same for me wihtin
Parse error: syntax error, unexpected 'class' (T_CLASS), expecting identifier (T_STRING) or variable (T_VARIABLE) or '{' or '$' in /Users/stephangrass/Documents/_Webs_/MR-Chemie/typo3/typo3_src-6.2.10/typo3/sysext/frontend/Classes/Imaging/GifBuilder.php on line 141
This worked for me: 4 or 5 times in this file:
... GeneralUtility::makeInstance('TYPO3\\CMS\\Frontend\\ContentObject\\ContentObjectRenderer');
#17 Updated by Christoph Lehmann 5 months ago
The applied changeset breaks PHP 5.3.10 too
